Industralight WPL300G Architectural LED Wall Pack Luminaire

Industralight WPL300G is an industrial quality LED wall pack luminaire. The product features a robust housing with high quality integrated LED light source and LED driver. WPL300G is a versatile product option and can be used for a variety of commercial applications such as security lighting, perimeter lighting, passageways, pathways, stairwells, commercial exterior and interior projects.

Electrical Parameters

Input Voltage120-240VAC
Max Power Consumption40W
LED Driver ClassificationIntegral Constant Current LED Driver
Light Source ClassificationCREE XP-E/T

Mechanical Specifications

Minimum IK RatingIK10
IP Protection RatingIP65
Dimensions158x353mm
ConstructionDie Cast Aluminium Body
Lens ConstructionToughened Polycarbonate
Standard Colour/FinishDark Bronze
Recommended Operating Temp-15°C – +50°C

Configuration Options

  • Various Optical Lens configurations available
  • Non standard fitting colours available by special request
  • Custom dimmable solutions available by special request

Photometric Information

Typical Light Source Efficacy80lm/W
CCT Colour Temperatures3000K / 4000K / 6500K
Colour Rendering Index [CRI]>80
Beam Angle / Viewing Angle120°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Series Model NumberWPL300G
Specify Wattage40W
Specify Optic Lens Config120° / 135×120° / Type II / Type III IES
Specify Fitting ColourDark Bronze
Specify Colour Temp3000K / 4000K / 6500K
Warranty InformationExtended Warranty Available
