ALT6100 LED Pole Fixture

Industralight ALT6100 is a high-quality pole fixture that features premium quality LED components. The professional luminaire is fixed onto a powdercoated steel pole and provides excellent area illumination for pathways, carparks and other commercial spaces. ALT6100 is available in a variety of powdercoated colours by special request.

Electrical Parameters

Input Voltage 100-240VDC
Max Power Consumption 45W
LED Driver Classification Integral Constant Current
Light Source Classification Epistar COB

Mechanical Specifications

Minimum IK Rating IK10
IP Protection Rating IP65
Pole Diameter 120mm
Overall Height 3.5mtrs
Head Dimensions 265x190mm
Construction Material High Pressure Aluminium
Standard Colour/Finish Corrosion Resistant Surface Treatment
Recommended Operating Temp -15°C – 45°C

Configuration Options

  • Non standard colours available by special request
  • Custom pole height by special request

Photometric Information

Typical Light Source Efficacy 90lm/W
CCT Colour Temperatures 3000K / 4000K / 6000K
Colour Rendering Index [CRI] >80
Beam Angle / Viewing Angle 75°

Detailed photometric report and IES files available by request
