Industralight Pantera PAN110 LED Downlight

Industralight Pantera is a high quality recessed LED downlight luminaire that delivers several advanced features and superior optical performance. Key features include semi-specular aluminium reflector, high efficiency lens, premium quality body and quality constant current LED driver. Pantera is available in several size configurations and is designed for high end commercial interior environments.

Electrical Parameters

Driver Input Voltage100-240VAC
Max Power Consumption15W
LED Driver ClassificationRemote – Constant Current
Light Source ClassificationCREE COB/3XD


Mechanical Specifications

Minimum IK RatingIK20
Ceiling Cutout100mm
Trim Diameter110mm
Overall Depth115mm
Standard Colour/FinishWhite with Silver Reflector
Recommended Operating Temp-15°C – 45°C


Configuration Options

  • Custom beam angle by special request
  • Non standard colours available by special request
  • DALI dimmable LED driver available by request


Photometric Information

Typical Light Source Efficacy90lm/W
CCT Colour Temperatures2700K/ 3000K / 4000K / 6000K
Colour Rendering Index [CRI]>80 / >95
Beam Angle / Viewing Angle60°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Series Model NumberPAN110
Specify Colour Temp2700K / 3000K / 4000K / 6000K
Wattage Option15W
Dimming ConfigurationNon-Dim / Phase Dimmable / DALI
Specify Beam Angle8° / 22° / 45° / 60°
Warranty InformationExtended Warranty Available

All product specifications are subject to change without notice. Industralight assumes no responsibility of errors or omissions. Please confirm product details prior to ordering.
