ITKL 80 LED Streetlight
Industralight ITKL is a professional lighting series with advanced LED technology. The product is available with a variety of IESNA optical variants and configuration options. ITKL is ideally suited for pole/spigot mounting, although Industralight can also supply several engineered mounting accessories for other mounting methods. ITKL is ideally suited to streetlighting, carparks, industrial sites, security lighting.
Electrical Parameters
| Input Voltage | 90-305VAC |
| Max Power Consumption | 80W |
| LED Driver Classification | Meanwell HLG Series |
| Light Source Classification | Luxeon T Series |
| Power Factor | >0.95 |
| Typical Efficiency | >90% |
Mechanical Specifications
| Minimum IK Rating | IK10 |
| IP Protection Rating | IP67 |
| Nominal Dimensions | 576x300x107mm |
| Construction Material | Aluminium & Polycarbonate |
| Spigot Entry Configuration | 63mm OD |
| Standard Colour/Finish | Black / White |
| Recommended Operating Temp | -25°C – 45°C |
Configuration Options
- DALI dimmable LED driver available by request
- Compatible with centralised control and network systems
- Pole and wall mounting systems available by request
Photometric Information
| Typical Light Source Efficacy | 120lm/W |
| CCT Colour Temperatures | 3000K / 4000K / 5000K / 6500K |
| Colour Rendering Index [CRI] | >80 |
| Beam Angle / Viewing Angle | 30° / 60° / 90° / 90°x100° |
| Optional IESNA Beam Angle | Type II 60°x150° / Type III A 70°x150° |
| Optional IESNA Beam Angle | Type III B 80°x150° |
Detailed photometric report and IES files available by request
