IL6064 LED Landscape Bollard

Industralight IL6064 LED is a high-quality LED bollard fixture for landscape lighting applications. The fitting is constructed from quality materials and incorporates new generation LED light source with advanced efficiency and optical performance. IL6064 is available in different colour finishes, and is suited for any commercial or residential application.

Electrical Parameters

Input Voltage 100-240VAC
Max Power Consumption 10W
LED Driver Classification Integral Constant Current
Light Source Classification High Power COB LED

Mechanical Specifications

Minimum IK Rating IK09
IP Protection Rating IP64
Profile Dimensions 60x60mm
Overall Height 800mm
Construction Material Extruded Aluminium
Standard Colour/Finish Corrosion Resistant
Recommended Operating Temp -15°C – 45°C

Configuration Options

  • Non standard colours available by special request
  • Integral DALI dimmable LED driver available by special request

Photometric Information

Typical Light Source Efficacy 100lm/W
CCT Colour Temperatures 3000K / 4000K / 6500K
Colour Rendering Indec [CRI] >80
Beam Angle/Viewing Angle 110°

Detailed photometric report and IES files available by request
