Industralight IL9612 LED Bollard Fixture

Industralight IL9612 is a high quality bollard fixture suitable for garden & landscape lighting. The product features a tilt adjustable head which is especially effective for pathways and passageway lighting proj­ects. IL9612 incorporates integral LED driver and exceeds IP65 protection rating for all outdoor applications.

Electrical Parameters

Input Voltage100-240VAC
Max Power Consumption16W
LED Driver ClassificationIntegral Constant Current
Light Source ClassificationCREE SMD3014

Mechanical Specifications

Minimum IK RatingIK09
IP Protection RatingIP65
Normal Bollard Height620mm
Fitting Dimensions225x140x75mm
Standard Colour/FinishMatt Silver
Recommended Operating Temp-10°C – +40°C

Configuration Options

  • Non standard colours available by special request
  • DALI dimmable LED driver available by request

Photometric Information

Typical Light Source Efficacy85lm/W
CCT Colour Temperatures3000K / 4200K / 6500K
Colour Rendering Index [CRI]>85
Beam Angle/Viewing Angle100°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Series Model NumberIL9612
Specify Colour Temp3000K / 4200K / 6500K
Specify Fixture Height625mm
Specify Wattage16W
Warranty InformationExtended Warranty Available
