WPK575 LED Wall Pack Luminaire
Industralight WPK575 is a professional wall-mounted luminaire for commercial and industrial projects. The body is manufactured from toughened materials with a vandal-resistant polycarbonate visor. WPK575 Wall-pack is ideal for general-purpose lighting in courtyards, common areas, carparks, security lighting, and commercial sites.
Electrical Parameters
| Input Voltage | 100-277VAC |
| Max Power Consumption | 45W / 70W / 100W / 150W |
| LED Driver Classification | Integral High Efficiency |
| Light Source Classification | Lumileds |
Mechanical Specifications
| Minimum IK Rating | IK10 |
| IP Protection Rating | IP65 |
| Nominal Dimensions | 370x230mm |
| Overall Depth From Wall | 198mm |
| Construction Material | Aluminium & Polycarbonate |
| Standard Colour/Finish | Black |
| Recommended Operating Temp | -30°C – 45°C |
Configuration Options
- Optional 200-480VAC version by special request
- DALI dimmable LED driver available by special request
Photometric Information
| Typical Light Source Efficacy | 110lm/W |
| CCT Colour Temperatures | 3000K / 4000K / 6500K |
| Colour Rendering Index [CRI] | >80 |
| Beam Angle / Viewing Angle | 130° |
Detailed photometric report and IES files available by request
