Industralight AEROLINE Linear Wall Luminaire

Industralight Aeroline is a quality luminaire with integral LED control gear and high efficiency light source. The luminaire is exterior rated and finished with a corrosion resistant surface treatment. Aeroline is available in different length configurations and  is ideally suited for high-end architectural projects, public spaces, landscape areas, and other commercial areas.

Electrical Parameters

Input Voltage100-240VAC
Max Power Consumption54W
LED Driver ClassificationIntegral Constant Current
Light Source ClassificationEpistar SMD2835

Mechanical Specifications

Minimum IK RatingIK08
IP Protection RatingIP65
Profile Dimensions95x55mm
Overall Length1000mm
Standard Colour/FinishBlack / White
Recommended Operating Temp-20°C – +45°C

Configuration Options

  • Custom sizes available by request
  • Non standard colours available by special request
  • DALI dimmable LED driver available by request

Photometric Information

Typical Light Source Efficacy90lm/W
CCT Colour Temperatures3000K / 4000K / 5000K
Colour Rendering Indec [CRI]>85
Beam Angle/Viewing Angle2×100°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Series Model NumberAER55
Specify Colour Temp3000K / 4000K / 5000K
Specify Fixture ColourBlack / White
Wattage Configuration2x27W
Warranty InformationExtended Warranty Available
