XL2122 LINEAR WALL LUMINAIRE -DIRECT/INDIRECT

XL2122 is a streamlined linear wall light designed specifically for above-bed use in retirement homes, hospitals, and linical settings. Offering optimal illumination, it ensures patient comfort and is both practical and durable for healthcare environments. Available in several modular lengths, XL2122 can be configured for independent switching or dimming control of the direct and indirect components.

ELECTRICAL PARAMETERS

Input Voltage: 100-240VAC
Power Consumption: 12W / 18W / 25W / 40W
LED Driver Classification: Integral Constant Current
Light Source Classification: SMD2835

MECHANICAL SPECIFICATIONS

Minimum IK Rating: IK08
IP Protection Rating: IP40
Profile Dimensions: 88x47mm
Construction Material: Die Cast Aluminum
Standard Colour/Finish: Black / White / Custom
Recommended Ambient Temp: -20˚C – 45˚C

CONFIGURATION OPTIONS

● Custom sizes available by request
● Non standard colours available by special request
● Integral DALI dimmable LED driver available by request

PHOTOMETRIC INFORMATION

Typical Lumen Efficacy: 90lm/W
CCT Colour Temperature: 3000K / 4000K / 5000K
Colour Rendering (Ra): >85Ra
Illumination Configuration: Direct-Indirect / Direct Only

CONFIGURATION OPTIONS

This product can be customised or configured according to the needs of your project. Dimming and control options are vailable by special request. Control protocols include DALI, Casambi, Wireless, 1-10V, analogue dimming.

COMPLIANCE & CERTIFICATION

● IESNA2002
● AS/NZS60598, LM79, LM80
● Lifespan: Exceeds 50,000hrs @ L70

ORDERING INFORMATION

Model Number: XL2122
Specify LED CCT: 3000K / 4000K/ 5000K
Specify Length: 614mm / 914mm / 1204mm
Specify Finish/Colour: Black / White / Custom
Specify Wattage: 12W-40W
Control Option: Non Dim / DALI
Configuration: Direct Only / Direct-Indirect

All product details are subject to change without notice. Final specifications may vary
