VT955 LED Beacon Fixture
The Industralight VT Series is a robust, heavy-duty fixture for general purpose and security lighting applications. The fittings are traditionally styled, but feature latest generation integrated LED light source. They are available in either wall-mount or ceiling-mount options.
Electrical Parameters
| Driver Input Voltage: | 120-277VAC |
| Power Consumption: | 19.7W |
| LED Driver Classification: | Integral, Constant Current |
| Light Source Classification: | Industralight Power-LED |
Mechanical Specifications
| Minimum IK Rating: | IK08 |
| IP Protection Rating: | IP65 |
| Nominal Dimensions: | 312x157mm |
| Material: | Die-Cast Alloy & Glass Construction |
Configuration Options
- Available in ceiling-mount or wall-mount options
- Fixture colour can be refinished
Photometric Information
| Typical Lumen Efficacy: | 60lm/W |
| CCT Colour Temperatures: | 3000K/4200K/5000K/6500K |
| Colour Rendering Index (CRI): | >85 |
| Beam Angle/Viewing Angle: | 180° |
Detailed photometric report and IES files available by request
