Industralight VCP300 Surface Mount LED Ceiling Fixture

Industralight VCP300 is an industrial grade ceiling mounted fixture that is suitable for general area lighting. The slimline fittings are constructed from powdercoated steel body with polycarbonate lens. VCP300 features integral LED light source and LED driver. Applications include cool rooms, ceiling/canopy lighting, commercial, projects, industrial projects.

Electrical Parameters

Input Voltage120-277VAC
Max Power Consumption40W
LED Driver ClassificationIntegral Constant Current
Light Source ClassificationCitizen / COB


Mechanical Specifications

Minimum IK RatingIK10
IP Protection RatingIP65
Nominal Dimensions268x115mm
Construction MaterialAluminium Alloy
Standard FinishUV Stabilised / Powdercoated
Recommended Operating Temp-10˚C – 45˚C


Configuration Options

  • Non standard trim colours available by special request
  • Integral DALI dimmable LED driver by special request


Photometric Information

Typical Lumen Efficacy85lm/W
CCT Colour Temperatures3000K / 4000K / 6000K
Colour Rendering Index [CRI]>80
Beam Angle/Viewing Angle120˚

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details

Series Model NumberVCP300
Specify Colour Temp3000K / 4000K / 6000K
Specify Body ColourDark Bronze / Black / White
Specify Wattage40W
Warranty InformationExtended Warranty Available

All product specifications are subject to change without notice. Industralight assumes no responsibility of errors or omissions. Please confirm product details prior to ordering.
