Industralight STR6000 Architectural Post-Top Fixture

Industralight STR6000 is a high grade architectural LED fixture for pole mounting. The fixtures are ideally suited to landscapes, architectural streetscapes, street lighting, carparks and public spaces.  The fixtures have integrated high power 40W LED and integral LED control gear.

Electrical Parameters

Input Voltage:100-265VAC
Power Consumption:40W
LED Driver Classification:Integral Constant Current
Light Source Classification:Samsung High-Power LED

Mechanical Specifications

Minimum IK Rating:IK07
IP Protection Rating:IP65
Head Dimensions:620mm(D) x 800mm(H)
Suits Nominal Pole Diameter:75mm
Material/Construction:Extruded Alloy Construction
Recommended Ambient Temp:-20°C – 45°C

Configuration Options

  • Non-standard colour finishes available by special request
  • Poles can be supplied by special request

Photometric Information

Typical Lumen Efficacy:90lm/W
CCT Colour Temperatures:3000K/4000K/5000K/6500K
Colour Rendering Index (CRI):>80
Viewing Angle:360° Effective Illumination

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty. Please see our warranty policy for full details.

Series Model Number:STR6000
Specify Wattage:40W
Specify Colour Temp:3000K/4000K/5000K/6500K
Specify Voltage Type:100-240VAC or 24VDC
Specify Colour:Black or Silver
Optional Pole:Specify Height
