Industralight STR6000 Architectural Post-Top Fixture
Industralight STR6000 is a high grade architectural LED fixture for pole mounting. The fixtures are ideally suited to landscapes, architectural streetscapes, street lighting, carparks and public spaces. The fixtures have integrated high power 40W LED and integral LED control gear.
Electrical Parameters
| Input Voltage: | 100-265VAC |
| Power Consumption: | 40W |
| LED Driver Classification: | Integral Constant Current |
| Light Source Classification: | Samsung High-Power LED |
Mechanical Specifications
| Minimum IK Rating: | IK07 |
| IP Protection Rating: | IP65 |
| Head Dimensions: | 620mm(D) x 800mm(H) |
| Suits Nominal Pole Diameter: | 75mm |
| Material/Construction: | Extruded Alloy Construction |
| Recommended Ambient Temp: | -20°C – 45°C |
Configuration Options
- Non-standard colour finishes available by special request
- Poles can be supplied by special request
Photometric Information
| Typical Lumen Efficacy: | 90lm/W |
| CCT Colour Temperatures: | 3000K/4000K/5000K/6500K |
| Colour Rendering Index (CRI): | >80 |
| Viewing Angle: | 360° Effective Illumination |
Detailed photometric report and IES files available by request
Lighting Design & Simulations
Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.
Warranty Information
Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty. Please see our warranty policy for full details.
