LPS860 Architectural Landscape LED Fixture

Industralight LPS860 LED fixtures are high quality architectural fixtures designed for parks & recreational areas, streetlighting, public landscaping, carparking areas etc. The fixtures have a high-quality integral LED light source and built-in electronic LED control gear. The fixtures feature toughened PMMA diffuser and are available in single-sided or double-sided option.

Electrical Parameters

Input Voltage: 100-240VAC
Power Consumption: 24W or 48W
LED Driver Classification: Integral Constant Current
Light Source Classification: Industralight 3528 SMD LED

Mechanical Specifications

IP Protection Rating: IP65
Nominal Height: 3000mm
Pole Profile Dimensions: 100mm x 150mm
Material/Construction: Extruded Alloy + Steel
Diffuser Material: Toughened PMMA Opal
Recommended Ambient Temp:  -20°C – 45°C

Configuration Options

  • Available in single-sided or double-sided options
  • Can be finished in matt black or matt silver
  • Optional 24VDC version available by special request
  • Non-standard colour finishes available by special request
  • Optional inground concrete J-Bolt anchor kit available

Photometric Information

Typical Lumen Efficacy: 110lm/W
CCT Colour Temperatures: 3000K/4000K/5000K
Colour Rendering Index (CRI): >85
Viewing Angle: 1×120° / 2×120°

Detailed photometric report and IES files available by request
