Industralight LPS873 Architectural Landscape LED Fixture
Industralight LPS LED fixtures are high quality architectural fixtures designed for parks & recreational areas, streetlighting, public landscaping, carparking areas etc. The fixtures have a high-quality integral LED light source and built-in electronic LED control gear. The fixtures feature toughened PMMA diffuser.
Electrical Parameters
| Input Voltage: | 100-240VAC |
| Power Consumption: | 45W |
| LED Driver Classification: | Integral Constant Current |
| Light Source Classification: | Cree XP-E LED |
Mechanical Specifications
| Minimum IK Rating: | IK07 |
| IP Protection Rating: | IP65 |
| Standard Height: | 4000mm |
| Pole Profile Dimensions: | 100mm x 100mm |
| Material/Construction: | Extruded Alloy + Steel |
| Diffuser Material: | Toughened PMMA Opal |
| Recommended Ambient Temp: | -20°C – 45°C |
Configuration Options
- Can be finished in matt black or matt silver
- Optional 24VDC version available by special request
- Non-standard colour finishes available by special request
- Optional inground concrete J-Bolt anchor kit available
Photometric Information
| Typical Lumen Efficacy: | 110lm/W |
| CCT Colour Temperatures: | 3000K/4000K/5000K |
| Colour Rendering Index (CRI): | >85 |
| Viewing Angle: | 120° |
Detailed photometric report and IES files available by request
Lighting Design & Simulations
Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.
Warranty Information
Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty. Please see our warranty policy for full details.
