MTR438 Recessed Inground Pathway Light
Industralight MTR438 is a compact fixture designed for inground installation in pathways and landscaped areas. MTR438 is manufactured from toughened materials for strong impact resistance, and incorporates a professional LED light source for maximum efficiency.
Electrical Parameters
| Input Voltage | 220-240VAC |
| Max Power Consumption | 3W |
| LED Driver Classification | Integral LED Driver |
| Light Source Classification | Edison LED |
Mechanical Specifications
| Minimum IK Rating | IK10 |
| IP Protection Rating | IP67 |
| Overall Diameter | 100mm |
| Overall Mounting Depth | 107.5mm |
| Construction Material | ADC Die Cast Aluminum |
| Standard Colour/Finish | Dark Grey |
| Recommended Operating Temp | -20°C – 50°C |
Configuration Options
- One-way, two-way, four-way versions also available
- Non standard colours available by request
Photometric Information
| Typical Light Source Efficacy | 85lm/W |
| CCT Colour Temperatures | 3000K / 4000K / 6000K |
| Colour Rendering Index [CRI] | >80 |
| Beam Angle/Viewing Angle | 110° |
Detailed photometric report and IES files available by request
