TR20112 LED Track Light

Industralight TR20112 is a professional LED track mounted spotlight with integrated LED light source and specular aluminium reflector. TR20112 is available in a variety of beam angles, colour options and other configurations. Applications include museums, galleries, retail environments, residential developments, other commercial and residential projects.

Electrical Parameters

Input Voltage 220-240VAC
Max Power Consumption 12W
LED Driver Classification Integral Constant Current
Light Source Classification CREE COB

Mechanical Specifications

IP Protection Rating IP20
Body Dimensions 59.5x138mm
Construction Material Extruded Aluminum
Track Adaptor Single-Circuit / Three-Circuit
Standard Colour/Finish White / Black
Recommended Operating Temp 15°C – 45°C

Configuration Options

  • Surface mounted version also available
  • Non standard colours available by special request
  • Integral phase dimmable LED driver available by special request

Photometric Information

Typical Light Source Efficacy 110lm/W
CCT Colour Temperatures 3000K / 4000K / 5000K
Colour Rendering Index [CRI] >80
Beam Angle / Viewing Angle 10° / 20° / 24° / 38° / 60°

Detailed photometric report and IES files available by request

Download data sheet Talk to a specialist
