Industralight CYN136 Surface Mount LED Downlight

Industralight CYN136 is an integrated surface mounted LED downlight. The luminaire incorporates a powerful integral LED light source, solid-state control gear and high performance specular reflector. CYN136 is ideally suited to residential and commercial projects that require a high-quality surface mounted solution.

Electrical Parameters

Input Voltage100-240VAC
Max Power Consumption13W / 18W
LED Driver ClassificationIntegral Constant Current
Light Source ClassificationSharp COB


Mechanical Specifications

Minimum IK RatingIK10
IP Protection RatingIP65
Body Diameter80mm
Overall Length136mm
Construction MaterialExtruded Aluminium
Standard Colour/FinishCorrosion Resistant Surface Treatment
Recommended Operating Temp-20˚C – 45˚C


Configuration Options

  • Non standard colours available by special request
  • DALI dimmable LED driver by special request


Photometric Information

Typical Lumen Efficacy95lm/W
CCT Colour Temperatures3000K / 4000K / 6500K
Colour Rendering Index (CRI)>85
Beam Angle/Viewing Angle10° / 30° / 50°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details

Series Model NumberCYN136
Specify Colour Temp3000K / 4000K / 6500K
Specify Fixture ColourBlack / White / Other
Specify Wattage13W / 18W
Beam Angle10° / 30° / 50°
Warranty InformationExtended Warranty Available

All product specifications are subject to change without notice. Industralight assumes no responsibility of errors or omissions. Please confirm product details prior to ordering.
