Industralight ITKL 240 LED Streetlight

Industralight ITKL is a professional lighting series with advanced LED technology. The product is available with a variety of IESNA optical variants and configuration options. ITKL is ideally suited for pole/spigot mounting, although Industralight can also supply several engineered mounting accessories for other mounting methods. ITKL is ideally suited to streetlighting, carparks, industrial sites, security lighting.

Electrical Parameters

Input Voltage90-305VAC
Max Power Consumption240W
LED Driver ClassificationMeanwell HLG Series
Light Source ClassificationLuxeon T Series
Power Factor>0.95
Typical Efficiency>90%

Mechanical Specifications

Minimum IK RatingIK10
IP Protection RatingIP67
Nominal Dimensions900x300x107mm
Construction MaterialAluminium & Polycarbonate
Spigot Entry Configuration63mm OD
Standard Colour/FinishBlack / White
Recommended Operating Temp-25°C – 45°C

Configuration Options

  • DALI dimmable LED driver available by request
  • Compatible with centralised control and network systems
  • Pole and wall mounting systems available by request

Photometric Information

Typical Light Source Efficacy120lm/W
CCT Colour Temperatures3000K / 4000K / 5000K / 6500K
Colour Rendering Index [CRI]>80
Beam Angle / Viewing Angle30° / 60° / 90° / 90°x100°
Optional IESNA Beam AngleType II 60°x150° / Type III A 70°x150°
Optional IESNA Beam AngleType III B 80°x150°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

ITKL Mounting Options

ITKL features an adjustable 90-degree locking spigot bracket. This allows the mounting angle to be adjusted as required. Optional ITKL mounting accessories include 60-80mm spigot adaptors, reducing adaptors, wall mount brackets, customised pole options and custom-fabricated hardware.

Series Model NumberITKL240
Specify Colour Temp3000K/4000K/5000K/6500K
Specify Fixture ColourBlack/White/Silver
Specify Beam Angle30°/60°/90°/90°x100°/Type II/Type III
Warranty InformationExtended Warranty Available
