Industralight IL6068 LED Landscape Uplight

Industralight IL6848 LED garden illuminator consists of an inground housing which incorporates a LED light source and clear polycarbonate illuminating rod. The LED light source is available in several colour options and provides subtle ambient illumination for garden lighting projects.

Electrical Parameters

Input Voltage100-240VAC / 24VDC
Max Power Consumption5W
LED Driver ClassificationIntegral / Constant Voltage
Light Source ClassificationCREE 1W

Mechanical Specifications

IP Protection RatingIP67
Inground Housing Diameter116mm
Recess Mounting Depth120mm
Rod Height330mm
Rod Diameter40mm
Construction MaterialStainless Steel & Acrylic Rod

Configuration Options

  • Rod height can be customised
  • RGB version available by special request

Photometric Information

Typical Light Source Efficacy80lm/W
CCT Colour Temperatures3000K / 6500K / RGB
Beam Angle/Viewing AngleIndirect

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Series Model NumberIL6848
Specify Colour Temp3000K / 6500K / RGB
Specify Rod Length 330mm
Specify Wattage 5W
 Warranty InformationExtended Warranty Available
