GRD80 POLE MOUNTED LED LUMINAIRE
GRD80 is a sleek yet powerful industrial pole-mounted luminaire engineered for streetlighting, carparks, and public spaces. Delivering robust LED lighting performance, it excels in reliability and energy efficiency. As an Australian lighting manufacturer, we follow stringent Australian standards for commercial lighting. Count on our Australian lighting products for broad-area illumination, safety, and long-term value in large-scale outdoor applications.
ELECTRICAL PARAMETERS
| Input Voltage: | 100-277VAC |
| Power Consumption: | 80W / 100W / 175W |
| LED Driver Classification: | Constant Current |
| Light Source Classification: | Philips SMD3030 |
MECHANICAL SPECIFICATIONS
| Minimum IK Rating: | IK08 |
| IP Protection Rating: | IP66 |
| Nominal Body Depth: | 88mm Slimline |
| Nominal Body Length: | 534x305x88mm |
| Construction Material: | Aluminium |
| Mounting Configuration: | Pole Mounted / Trunnion Mounted |
| Recommended Ambient Temp: | -20˚C – 60˚C |
CONFIGURATION OPTIONS
- Available in custom colours by special request
- Optional sensor and PE photocell by request
- Multiple trunnion and pole mounting accessories by request
PHOTOMETRIC INFORMATION
| Typical Lumen Efficacy: | 130-155lm/W |
| CCT Colour Temperature: | 3000K / 4000K / 5000K / 5700K |
| Colour Rendering (Ra): | >80Ra |
| Beam Angle/Viewing Angle: | Refer to photometric diagrams |
CONTROL OPTIONS
GRD80 can be fitted with automatic motion sensor and/or NEMA accessories including PE cell or built-in time clock automaton. Dimming and control options are available by special request. Control protocols include DALI, Casambi, Wireless, 1-10V, analogue dimming.
COMPLIANCE & CERTIFICATION
- IESNA2002
- AS/NZS60598, LM79, LM80
- Lifespan: Exceeds 50,000hrs @ L70
ORDERING INFORMATION
| Model Number: | GRD80 |
| Specify LED CCT: | 3000K / 4000K / 5000K / 5700K |
| Specify Wattage Size: | 80W / 100W / 175W |
| Colour Finish: | Dark Grey (GY) / White (WH) / Custom |
| Optional Accessory: | Wall Mounted Spigot Bracket |
| Control Option: | Non-Dimmable / 1-10V / PE Cell / Sensor |
All product details are subject to change without notice. Final specifications may vary.
