Industralight Euro® LED Bollard Series 186mm

Industralight Euro® LED Bollards are a professional solution for walkways, pathways and security lighting application for a wide range of projects.  Euro® LED Bollards are constructed from high strength materials and feature high efficiency LED components and integral LED control gear.

Electrical Parameters

Input Voltage:100-265VAC
Power Consumption:20W
LED Driver Classification:Integral Constant Current
Light Source Classification:XP-E Power LED

Mechanical Specifications

Minimum IK Rating:IK06
IP Protection Rating:IP65
Nominal Body Diameter:186mm
Nominal Height:520mm or 950mm
Material/Construction:Extruded Alloy/Powdercoated
Recommended Ambient Temp:-20°C – 45°C

Configuration Options

  • Available with round, cone, oval or flat top options
  • 24VDC version available by special request
  • Non-standard colour finishes available by special request

Photometric Information

Typical Lumen Efficacy:85-90lm/W
CCT Colour Temperatures:3200K/4200K/6500K
Colour Rendering Index (CRI):>85
Viewing Angle:360° Effective Illumination

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.  Please see our warranty policy for full details.

Series Model Number:EUR LED Bollard 186mm
Specify Colour Temp:3200K/4200K/6500K
Height Option:520mm or 950mm
Specify Colour:Black or Matt Grey
Specify Bollard Top StyleCone Top/Oval Top/Dome Top/Flat Top
