ALT8800 Landscape LED Pole Fixture
Industralight ALT8800 is a high-quality pole fixture that features premium quality LED components. The professional luminaire is top-mounted onto the powdercoated steel pole and provides excellent indirect area illumination for pathways, carparks and other commercial spaces. ALT8800 is available in a variety of powdercoated colours by special request.
Electrical Parameters
| Input Voltage | 100-240VDC |
| Max Power Consumption | 45W |
| LED Driver Classification | Integral Constant Current |
| Light Source Classification | Epistar COB |
Mechanical Specifications
| Minimum IK Rating | IK09 |
| IP Protection Rating | IP65 |
| Body Overall Diameter | 266mm |
| Overall Height | 3mtrs |
| Standard Colour/Finish | Opal Grey / Dark Grey |
| Recommended Operating Temp | -15°C – 45°C |
Configuration Options
- Non standard colours available by special request
- DALI dimmable LED driver available by request
Photometric Information
| Typical Light Source Efficacy | 100lm/W |
| CCT Colour Temperatures | 3000K / 4000K / 5000K |
| Colour Rendering Index [CRI] | >80 |
| Beam Angle / Viewing Angle | 110° |
Detailed photometric report and IES files available by request
