Industralight DMX600 Digital DMX Phase Dimmer

Industralight DMX600 is a powerful 240V dimming controller designed for specific commercial applications. The device has four 240V channel outputs which can control phase dimmable 240V products. DMX600 can accept 1-10V or DMX512 signal input and is ideal for industrial use, poultry farm facilities and other commercial projects.

Electrical Parameters

Input Voltage90-240VAC
Input ProtocolDMX512 (1990)
Output ProtocolPhase Dimmable
Auxiliary Output Protocol1-10V
Output Channels4 x Addressable Outputs
Maximum Output Load12A

Mechanical Specifications

Mounting MethodDin Rail Mounted
IP Protection RatingIP20
Nominal Dimensions190(W)x88(H)x57(D)mm
Connection MethodScrew Terminals
Recommended Operating Temp-10°C – 40°C
Net Weight590g

Configuration Options

  • Pre-configured DMX input control available by request
  • Compatible with Industralight lighting control software

Typical Applications

Industrial Projects, Poultry Farm Facilities, Commercial Projects, Lighting Automation

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Model NumberDMX600
Input ProtocolDMX512 (1990)
  Output ProtocolPhase Dimmable / 1-10V
  Warranty InformationExtended Warranty Information
