EXD930P150 MODULAR EXD FLOODLIGHT
EXD930 is a pole mounted industrial luminaire for use in hazardous locations. Ideal for car parking, work areas, depots, streetlighting and other pole ,mounted applications. Ideal for Oil refineries, exploration sites, chemical industries, power plants and more. Strong protection against corrosion and harsh chemicals.
Electrical Parameters
| Input Voltage: | 120-277VAC |
| Rated Frequency: | 50Hz / 60Hz |
| Power Consumption: | 150W |
| LED Driver Classification: | Integral, Constant Current |
| Light Source Classification: | CREE High Power LED |
| Zone Classification: | Zone 1 / Zone 2 / Zone 21 / Zone 22 |
| Gas Explosive Group: | Group IIA, IIB, IIC |
Mechanical Specifications
| Minimum IK Rating: | IK10 |
| IP Protection Rating: | IP66 |
| Body Dimensions: | 497(L)x305(W)x93mm(H) |
| Construction Material: | Powdercoated Aluminium |
| Standard Colour/Finish: | Grey / Signal Yellow |
| Recommended Ambient Temp: | -40 ̊C to 55 ̊C |
| Net Weight: | 11.7Kg |
| Spigot Entry: | Φ55~Φ60 |
Configuration Options
- Suitable for Pole Spigot 60mm OD / 40-55mm OD By Request
- Compliant with Temperature group T1- T6
- Exd Rated Junction Box and Accessories available by request
Photometric Information
| Typical Lumen Efficacy: | 125lm/W |
| CCT Colour Temperature: | 3000K / 4000K / 5000K |
| Colour Rendering (Ra): | >70Ra / 80Ra |
| Beam Angle/Viewing Angle: | 60° x 80° |
