ITR90 Adjustable LED Track Light
Industralight ITR90 is an architectural LED track-mounted spotlight with adjustable pivot design. The fitting is manufactured from extruded alloy with high grade powdercoated finish. ITR90 is designed for high quality interior projects such as hotels, hospitality projects, retail environments, high-end residential, commercial projects.
Electrical Parameters
| Input Voltage | 240VAC |
| Max Power Consumption | 22W |
| LED Driver Classification | Integral – Phase Dimmable |
| Light Source Classification | Sharp COB |
Mechanical Specifications
| IP Protection Rating | IP20 |
| Track Adaptor | Single Circuit or Three Circuit |
| Overall Height | 210mm |
| Body Diameter | 105mm |
| Construction Material | Aluminium |
| Standard Colours Available | White / Black |
| Recommended Operating Temp | -20°C – 40°C |
Configuration Options
- Available with single-circuit or three-circuit trak adaptor
- Non standard colours available by special request
- DALI dimmable LED driver available by request
Photometric Information
| Typical Light Source Efficacy | 100lm/W |
| CCT Colour Temperatures | 2700K / 3000K / 4000K / 5000K |
| Colour Rendering Index [CRI] | >90 |
| Beam Angle / Viewing Angle | 8° / 15° / 24° / 40° |
Detailed photometric report and IES files available by request
