Industralight CDL9371 Surface Mount LED Downlight
Industralight CDL937 surface mounted LED downlights are commercial grade, stylish fittings for locations that require a surface mounted downlight solution. The fittings have integral LED driver and are protected to IP65 making them suitable for all indoor and outdoor applications.
Electrical Parameters
| Input Voltage: | 100-265VAC |
| Power Consumption: | 39W |
| LED Driver Classification: | Integral Constant Current |
| Light Source Classification: | XP-E LED |
Mechanical Specifications
| Minimum IK Rating: | IK06 |
| IP Protection Rating: | IP65 |
| Nominal Dimensions: | 180mm(D) x 300mm(H) |
| Material/Construction: | Extruded Alloy/Powdercoated |
| Recommended Ambient Temp: | -20°C – 45°C |
Configuration Options
- 24VDC version available by special request
- Non-standard colour finishes available by special request
Photometric Information
| Typical Lumen Efficacy: | 85-95lm/W |
| CCT Colour Temperatures: | 3200K/4200K/6500K |
| Colour Rendering Index (CRI): | >85 |
| Beam Angle/Viewing Angle: | 24° or 60° |
Detailed photometric report and IES files available by request
Lighting Design & Simulations
Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.
Warranty Information
Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty. Please see our warranty policy for full details.
