Vega® Architectural LED Floodlight
Industralight Vega® LED fixtures are stylish and functional floodlights suitable for a wide range of high-end commercial and industrial projects. They are available in a variety of power and beam angle configurations as well as several different mounting options.
Electrical Parameters
Input Voltage: | 90-305VAC |
Power Consumption: | 13W / 18W / 26W / 52W |
LED Driver Classification: | Integral Constant Current |
Light Source Classification: | CTZ Power-LED |
Mechanical Specifications
Minimum IK Rating: | IK08 |
IP Protection Rating: | IP66 |
LED Qty: | Single / Twin / Quad |
Fixture Material: | Powdercoated Alloy |
Standard Colour Finish: | Silver |
Adjustable Bracket: | 160° Swivel Bracket |
Recommended Ambient Temp: | -40°C – 50°C |
Configuration Options
- Trunnion mount bracket included
- Optional 24VDC version available by special request
- 1-10V dimmable driver available by special request
Photometric Information
Typical Lumen Efficacy: | 70lm/W |
CCT Colour Temperatures: | 3200K/4000K/5500K |
Colour Rendering Index (CRI): | >80 |
Beam Angle: | 18° / 36° / 120° / 160° |
Detailed photometric report and IES files available by request
