Industralight Vega® Architectural LED Floodlight

Industralight Vega® LED fixtures are stylish and functional floodlights suitable for a wide range of high-end commercial and industrial projects. They are available in a variety of power and beam angle configurations as well as several different mounting options.

Electrical Parameters

Input Voltage:90-305VAC
Power Consumption:13W / 18W / 26W / 52W
LED Driver Classification:Integral Constant Current
Light Source Classification:CTZ Power-LED

Mechanical Specifications

Minimum IK Rating:IK08
IP Protection Rating:IP66
LED Qty:Single / Twin / Quad
Fixture Material:Powdercoated Alloy
Standard Colour Finish:Silver
Adjustable Bracket:160° Swivel Bracket
Recommended Ambient Temp:-40°C – 50°C

Configuration Options

  • Trunnion mount bracket included
  • Optional 24VDC version available by special request
  • 1-10V dimmable driver available by special request

Photometric Information

Typical Lumen Efficacy:70lm/W
CCT Colour Temperatures:3200K/4000K/5500K
Colour Rendering Index (CRI):>80
Beam Angle:18° / 36° / 120° / 160°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty. Please see our warranty policy for full details.

Series Model Number:VFL Series
Power Variant:13W / 18W / 26W / 52W
Specify Voltage:100-240VAC or 24VDC
Specify Colour Temp:3000K/4000K/5000K
Specify Beam Angle:18° / 36° / 120° / 160°
Specify Mounting Type:Trunnion / Knuckle Bracket
Dimmable Options:1-10V Dimmable By Request
