Rebel® LED Floodlight Series 600W-RGBW

Industralight Rebel® series is a family of high quality LED floodlight fixtures which can be used for a variety of commercial and industrial lighting applications. Industralight Rebel LED floodlights are supplied integral LED driver and multi-purpose adjustable trunnion bracket. Typical applications include billboards & signage, area floodlighting, pole lighting, container and shipyards, industrial sites, warehousing, streetlighting, security lighting and more. Full colour dynamics via digital control, options include DMX512, Wireless and more.

Electrical Parameters

Input Voltage: 90-305VAC
Max Power: 600W
LED Driver Classification: Meanwell HLG Series
Light Source Classification: Luxeon® ES LED

Mechanical Specifications

Minimum IK Rating: IK10
IP Protection Rating: IP65
Adjustable Mounting Bracket: 180° Adjustable Trunnion Bracket
Material/Construction: Toughened Alloy Construction
Nominal Dimensions: 811x606x369mm
Recommended Ambient Temp: -40°C – 50°C

Configuration Options

  • Control options: DMX512, DALI-2, DT8, Casambi Wireless
  • RGB / RGBW / RGBW+Tunable LED
  • Adjustable mounting bracket included
  • Available in non standard colours by special request
  • 24VDC version available by special request

Photometric Information

Typical Lumen Efficacy:65- 70-110lm/W
CCT Colour Temperatures: RGB / RGBW (3000k /4000k)
Colour Rendering Index (CRI): >70 / >80
Beam Angle/Viewing Angle: 15° / 30° / 85° / 135°x85°

Detailed photometric report and IES files available by request


Download data sheet Talk to a specialist
