Rebel® LED Floodlight Series 600W-RGBW
Industralight Rebel® series is a family of high quality LED floodlight fixtures which can be used for a variety of commercial and industrial lighting applications. Industralight Rebel LED floodlights are supplied integral LED driver and multi-purpose adjustable trunnion bracket. Typical applications include billboards & signage, area floodlighting, pole lighting, container and shipyards, industrial sites, warehousing, streetlighting, security lighting and more. Full colour dynamics via digital control, options include DMX512, Wireless and more.
Electrical Parameters
| Input Voltage: | 90-305VAC |
| Max Power: | 600W |
| LED Driver Classification: | Meanwell HLG Series |
| Light Source Classification: | Luxeon® ES LED |
Mechanical Specifications
| Minimum IK Rating: | IK10 |
| IP Protection Rating: | IP65 |
| Adjustable Mounting Bracket: | 180° Adjustable Trunnion Bracket |
| Material/Construction: | Toughened Alloy Construction |
| Nominal Dimensions: | 811x606x369mm |
| Recommended Ambient Temp: | -40°C – 50°C |
Configuration Options
- Control options: DMX512, DALI-2, DT8, Casambi Wireless
- RGB / RGBW / RGBW+Tunable LED
- Adjustable mounting bracket included
- Available in non standard colours by special request
- 24VDC version available by special request
Photometric Information
| Typical Lumen Efficacy:65- | 70-110lm/W |
| CCT Colour Temperatures: | RGB / RGBW (3000k /4000k) |
| Colour Rendering Index (CRI): | >70 / >80 |
| Beam Angle/Viewing Angle: | 15° / 30° / 85° / 135°x85° |
Detailed photometric report and IES files available by request
