Industralight Rebel® 1000 Modular LED Floodlight

Industralight Rebel® 1000 is an industrial LED floodlight system which can be used for a variety of industrial lighting applications. Rebel LED floodlights are supplied integrated LED driver and multi-purpose adjustable trunnion bracket. Typical applications include billboards & signage, area floodlighting, pole lighting, container and shipyards, industrial sites, warehousing, streetlighting, security light­ing and more.

Electrical Parameters

Input Voltage90-305VAC
Max Power Consumption1000W
LED Driver ClassificationMeanwell
Light Source ClassificationRebel LED

Mechanical Specifications

Minimum IK RatingIK10
IP Protection RatingIP65
Nominal Dimensions833x764x170mm
Construction MaterialToughened Aluminium
Standard Colour/FinishBlack / Corrosion Resistant
Recommended Operating Temp-40°C – 50°C

Configuration Options

  • Several beam angle / optics available
  • Non standard colours available by special request
  • DALI dimmable LED driver available by request

Photometric Information

Typical Light Source Efficacy110lm/W
CCT Colour Temperatures3000K / 4000K / 5000K / 5700K
Colour Rendering Index [CRI]>80
Beam Angle/Viewing Angle10° / 15° / 30° / 90°
Optional ConfigurationSeveral Asymmetrical Options Available

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Series Model NumberRebel-1000 / RF1000
Specify Colour Temp3000K / 4000K / 5000K / 5700K
Specify Beam Angle10° / 15° / 30° / 90°
Optional Asymmetrical Optic85×45° / 85×90° / 85×135°
Specify Wattage1000W
Warranty InformationExtended Warranty Available
