ITS90 Surface Mounted LED Spotlight
Industralight ITS90 is an architectural LED ceiling spotlight with unique adjustable pivot design. The fitting is manufactured from extruded alloy with high grade powdercoated finish. ITS90 is designed for high quality interior projects such as hotels, hospitality projects, retail environments, high-end residential, commercial projects.
Electrical Parameters
| Input Voltage | 240VAC |
| Max Power Consumption | 22W |
| LED Driver Classification | Integral – Phase Dimmable |
| Light Source Classification | Sharp COB |
Mechanical Specifications
| IP Protection Rating | IP20 |
| Mounting Method | Ceiling Mount / Surface Mount |
| Overall Height | 210mm |
| Body Diameter | 105mm |
| Construction Material | Aluminium |
| Standard Colours Available | White / Black |
| Recommended Operating Temp | -20°C – 40°C |
Configuration Options
- Also available as a track mounted model – ITR90
- Non standard colours available by special request
- DALI dimmable LED driver available by request
Photometric Information
| Typical Light Source Efficacy | 100lm/W |
| CCT Colour Temperatures | 2700K / 3000K / 4000K / 5000K |
| Colour Rendering Index [CRI] | >90 |
| Beam Angle / Viewing Angle | 8° / 15° / 24° / 40° |
Detailed photometric report and IES files available by request
