MFL230P REGAL® POLE MOUNTED LED FLOODLIGHT

Regal® MFL is a modular high mast LED floodlight luminaire for use in sports stadiums, large sports fields, industrial areas and a variety of other commercial lighting and industrial lighting applications. MFL can be configured with different options and all parts are interchangeable and modular allowing for high degree of customisation. Commercial & industrial LED lighting, floodlighting, sports lighting. rugby, lighting, football lighting, parks & landscapes.

Electrical Parameters

Input Voltage: 90-305VAC
Power Consumption: 230W
LED Driver Classification: Meanwell, ELG/HLG
Light Source Classification: Lumileds® SMD LED
Surge Protection: SPD 6KV

Mechanical Specifications

Minimum IK Rating: IK10
IP Protection Rating: IP66
Nominal Dimensions: 320x324x3275mm
Construction Material: Toughened Alloy Construction
Lens Material: Toughened Polycarbonate
Recommended Ambient Temp: -20 ̊C – 50 ̊C

Main Features

  • MFL230P Pole Mounted using PA2TR
  • Optional Control via DALI / 1-10V / Analogue / Wireless DMX
  • Configurable optical arrangements
  • Glare Protection Accessories Available By request
  • Optional Bird Protection Kit by Request

Photometric Information

Typical Lumen Efficacy: 135-145lm/W
CCT Colour Temperature: 3000K/4000K/5700K/6500K
Colour Rendering Index (CRI): >85Ra
Beam Angle/Viewing Angle: 25 ̊ / 60 ̊ / 90 ̊ / 130 ̊x25 ̊ / 130 ̊x60 ̊

Configuration Options

Modular system available in power configurations from 75W-1200W. Mechanical cable protection and other mounting accessories available by request.
