MFL075 REGAL® HIGH MAST LED FLOODLIGHT
Regal® MFL is a modular high mast LED floodlight luminaire for use in sports stadiums, large sports fields, industrial areas and a variety of other commercial lighting and industrial lighting applications. MFL can be configured with different options and all parts are interchangeable and modular allowing for high degree of customisation. Commercial & industrial LED lighting, floodlighting, sports lighting. rugby, lighting, football lighting, parks & landscapes.
Electrical Parameters
| Input Voltage: | 90-305VAC |
| Power Consumption: | 75W |
| LED Driver Classification: | Meanwell, ELG/HLG |
| Light Source Classification: | Lumileds® SMD LED |
| Surge Protection: | SPD 6KV |
Mechanical Specifications
| Minimum IK Rating: | IK10 |
| IP Protection Rating: | IP66 |
| Nominal Dimensions: | 320x130x225mm |
| Construction Material: | Toughened Alloy Construction |
| Lens Material: | Toughened Polycarbonate |
| Recommended Ambient Temp: | -20 ̊C – 45 ̊C |
Main Features
- Optional Control via DALI / 1-10V / Analogue / Wireless DMX
- Configurable optical arrangements
- Glare Protection Accessories Available By request
- Optional Bird Protection Kit by Request
Photometric Information
| Typical Lumen Efficacy: | 135-145lm/W |
| CCT Colour Temperature: | 3000K/4000K/5700K/6500K |
| Colour Rendering Index (CRI): | >85Ra |
| Beam Angle/Viewing Angle: | 25 ̊ / 60 ̊ / 90 ̊ / 130 ̊x25 ̊ / 130 ̊x60 ̊ |
Configuration Options
Modular system available in power configurations from 75W-1200W. Mechanical cable protection and other mounting accessories available by request.
