Industralight XT Series LED Panel

Industralight XT is a high performance LED lightguide panel with slimline design and excellent lumen performance. The product is manufactured in a variety of sizes and LED configurations. Industralight XT panels also features the unique click-rail frame design which provides a professional system for connection of attachments and accessories such as suspension kits and mounting hardware.

Electrical Parameters

Input Voltage100-240VAC
Max Power Consumption18-72W
LED Driver ClassificationRemote Mounted Constant Current
Light Source ClassificationMicro SMD LED


Mechanical Specifications

IP Protection RatingIP44
Nominal DiametersVarious sizes 300mm – 1200mm
Panel Thickness12mm
Construction MaterialAerospace Grade Aluminium + PMMA
Standard Colour/FinishPolycarbonate
Installation MethodSurface Mounted / Wire Suspension / Recessed
Recommended Operating Temp-15°C – 45°C


Configuration Options

  • Wide variety of mounting hardware accessories available by request
  • 1-10V dimmable LED driver available by request
  • DALI dimmable LED driver available by request


Photometric Information

Typical Light Source Efficacy100lm/W
CCT Colour Temperatures3000K / 4000K / 5000K / 6500K
Colour Rendering Index [CRI]>90
Unified Glare Rating [UGR]<19UGR
Beam Angle/Viewing Angle120°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details

Series Model NumberXT Series
Specify Colour Temp3000K / 4000K / 5000K / 6500K
Specify Diameter300mm / 600mm / 900mm / 1200mm
Specify Wattage18W / 28W / 32W / 48W / 72W / 90W
Specify Installation ConfigurationWire Suspension / Ceiling Recessed
Optional Installation AccessoriesSurface Mount Kits / Suspension / Bracket Kits



All product specifications are subject to change without notice. Industralight assumes no responsibility of errors or omissions. Please confirm product details prior to ordering.
