VBR Polycarbonate Slim/Low-Profile Linear LED Fixture

Industralight VBR2 is a dual-diffused low profile LED fixture that is constructed from fire-resistant polycarbonate body and diffuser. VBR fixtures are available in several different size configurations and are ideal for installation into modern commercial environments including offices, storerooms, workshops, schools, retail showrooms etc.

Electrical Parameters

Input Voltage: 100-240VAC
Power Consumption: 20W/24W/30W/40W/48W
LED Driver Classification: Integral, Constant Current
Light Source Classification: Industralight SMD2835 LED

Mechanical Specifications

Minimum IK Rating: IK10
IP Protection Rating: IP20
Nominal Fixture Lengths: 1226x120x40mm
Construction Material: Fire Resistant Toughened Polycarbonate

Configuration Options

  • Surface mounted low profile
  • 24VDC version available by special request

Photometric Information

Typical Lumen Efficacy: 130lm/W
CCT Colour Temperatures: 3000K/4000K/5000K/6500K
Colour Rendering Index (CRI): >90
Beam Angle/Viewing Angle: 120°

Detailed photometric report and IES files available by request
