Industralight MMS20 Magnetic Track LED Spotlight

Industralight MMS20 is a miniature LED spotlight which features a unique magnetic track rail mounting system. Each MMS20 LED spotlight is individually swivel adjustable and can be easily positioned along the track rail. MMS20 is a professional lighting system that is ideal for retail environments, display cases, museums, galleries, showrooms and other special purpose display lighting projects.

Electrical Parameters

Input Voltage12-24VDC
Max Power Consumption4.5W
LED Driver ClassificationRemote Mounted
Light Source ClassificationCREE 1304


Mechanical Specifications

Minimum IK RatingNA
IP Protection RatingIP20
Nominal Dimensions55x30x50mm
Mounting SystemTrack + Magnetic Couple
Standard Colour/FinishBlack
Recommended Operating Temp-15°C – 45°C


Configuration Options

  • Non standard colours available by special request
  • Magnetic
  • DALI dimmable LED driver available by request


Photometric Information

Typical Light Source Efficacy100lm/W
CCT Colour Temperatures3000K / 4000K / 6500K
Colour Rendering Index [CRI]>90
Beam Angle / Viewing Angle-45°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details

Series Model NumberMMS20
Specify Colour Temp3000K / 4000K / 6500K
Specify Track Length1mtr / 2mtr Lengths Available
Dimming OptionDALI / Push-Dim / Non-Dimmable
Warranty InformationExtended Warranty Available

All product specifications are subject to change without notice. Industralight assumes no responsibility of errors or omissions. Please confirm product details prior to ordering.
