Industralight FL7015 LED Floodlight – 15W

Industralight FL7 is a new generation LED floodlight with integrated mains voltage LED module. FL7 delivers superior lumen output with optimum efficiency. The fittings are manufactured from robust materials and can be used in any Industrial, commercial or residential environment.

Electrical Parameters

Input Voltage85-285VAC
Max Power Consumption15W
LED Driver ClassificationClass 1
Light Source ClassificationOsram 3030T

Mechanical Specifications

Minimum IK RatingIK09
IP Protection RatingIP65
Nominal Dimensions169x132x53mm
Construction MaterialAluminium
Standard Colours/FinishBlack / Corrosion Resistant
Recommended Operating Temp-20°C – 50°C

Configuration Options

  • Other size configurations up to 200W available by request
  • Non standard colours available by special request
  • DALI dimmable version available by special request

Photometric Information

Typical Light Source Efficacy100lm/W
CCT Colour Temperatures3000K / 4000K / 5000K / 6500K
Colour Rendering Index [CRI]>80
Beam Angle/Viewing Angle120°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Series Model NumberFL7015
Specify Colour Temp3000K / 4000K / 5000K / 6500K
Specify Wattage15W
Included Mounting AccessoryAdjustable Bracket
Warranty InformationExtended Warranty Available
