Industralight KLS500 Surface Mount LED Wall Light

Industralight KLS500 is an exterior wall mounted fitting with integral LED driver and SMD LED light source. The fitting is entirely surface mounted making it ideal for installation onto solid walls such as concrete or masonry. KLS500 is ideal for pathways and steplighting and can be fitted with an integral PIR sensor for a simple automation solution.

Electrical Parameters

Input Voltage220-240VAC
Max Power Consumption6W
Light Source ClassificationEpistar SMD LED

Mechanical Specifications

Minimum IK RatingIK10
IP Protection RatingIP54
Nominal Diameter150mm
Overall Depth34mm
Construction MaterialAluminium
Standard Colour/FinishDark Grey
Recommended Operating Temp-10°C – 40°C

Configuration Options

  • Non standard colours available by special request
  • Optional 24VDC constant voltage version by request

Photometric Information

Typical Light Source Efficacy85lm/W
CCT Colour Temperatures3000K / 4000K / 6500K
Colour Rendering Index [CRI]>80
Beam Angle/Viewing Angle120°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Series Model NumberKLS500
Specify Colour Temp3000K / 4000K / 6500K
Specify Input Voltage220-240VAC / 24VDC
Specify ColourDark Grey / Black / White
IP RatingIP54
