W6380 is a commercial grade wall light with solid extruded body, and powdercoated. Corrosion resistant marine grade finish makes the product good for use in all exterior locations. Tempered glass visor and integrated LED control gear. Available in up and down or down only variants with various other custom lighting options.

Electrical Parameters

Input Voltage: 220-240VAC
Power Consumption: 12W / 24W
LED Driver Classification: Constant Current
Light Source Classification: Epistar SMD2835 LED

Mechanical Specifications

Minimum IK Rating: IK10
IP Protection Rating: IP65
Dimensions: 350mm
Body Width: 120mm
Overall Projection From Wall: 100mm
Construction Material: Aluminium
Standard Colour/Finish: Black / White / Silver / Custom
Recommended Ambient Temp: -15°C – 55°C

Configuration Options

  • Non standard colours available by special request
  • Remote mounted DALI dimmable LED driver available

Photometric Information

Typical Lumen Efficacy: 85lm/W
CCT Colour Temperatures: 3000K / 4000K / 6000K / RGBW
Colour Rendering Index (CRI): >85Ra
Beam Angle/Viewing Angle: 100°

Control Options

This product can be customised or configured according to the needs of your project. Dimming and control options are available by special request. Control protocols include DALI, Casambi, Wireless, 1-10V, analogue dimming.
