SR400Y Architectural LED Landscape Floodlight
Industralight SR400Y is a high quality architectural LED spotlight projector/floodlight that features commercial grade materials and superior optical performance. The fixtures can be customised with different beam angles, and a variety of LED colour temperatures including RGB for fully controllable colour spectrum output. Typical applications include landscape and feature lighting, sculptures and flagpole illumination, garden lighting and architectural highlighting.
Electrical Parameters
| Input Voltage: | 100-240VAC or 12VDC |
| Power Consumption: | 11W or 20W |
| LED Driver Classification: | Integral, Constant Current |
| Light Source Classification: | CREE XP-LED |
Mechanical Specifications
| Minimum IK Rating: | IK06 |
| IP Protection Rating: | IP66 |
| Nominal Dimensions: | 140mm(L) x 130mm(D) x 180mm(H) |
| Material: | Powdercoated High-Grade Alloy |
Configuration Options
- Y-bracket included
- 100-240VAC or 12VDC options
- Custom fixture colours available by special request
Photometric Information
| Typical Lumen Efficacy: | 85lm/W |
| CCT Colour Temperatures: | 3000K/4000K/6500K/RGB |
| Typical Colour Rendering Index (CRI): | >85 |
| Beam Angle/Viewing Angle: | 6°/12°/15°/20°/30°/45° |
Detailed photometric report and IES files available by request
