Industralight Trek 60 Linear Lighting System

Industralight Trek 60 is a modern LED luminaire that integrates onto conventional three-circuit track systems. The product is built with high grade materials and is available with powerful LED output configurations. Trek 60 can be used for museums, galleries, retail spaces, industrial lighting, and other commercial projects.

Electrical Parameters

Input Voltage220-240VAC / 110-277VAC
Max Power Consumption30W / 40W / 60W
LED Driver ClassificationIntegral Constant Current
Light Source ClassificationEpistar SMD


Mechanical Specifications

IP Protection RatingIP40
Luminaire Profile Dimensions60(w)x86(h)mm
Luminaire Profile Dimensions343mm / 363mm / 493mm
Construction MaterialAluminium
Standard Colour/FinishPowdercoated
Recommended Operating Temp-40°C – 45°C


Configuration Options

  • Industralight can design and supply complete three-circuit track systems as required
  • Special colour finishes available by request
  • Integral DALI dimmable LED driver available by request
  • Custom light distribution configurations available


Photometric Information

Typical Light Source Efficacy140lm/W
CCT Colour Temperatures3000K / 4000K / 5000K
Colour Rendering Index [CRI]>85
Beam Angle / Viewing Angle22° / 45° / 90°
Optional Light DistributionAsymmetrical / Wall Washing
UGR Glare Rating<19 UGR

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Series Model NumberTrek-60 (TRK60)
Wattage Configuration30W / 40W / 60W
Specify Colour Temp3000K / 4000K / 5000K
Specify Fixture ColourBlack / White / Silver
Specify Beam Angle22° / 45° / 90°
Light Distribution ModeSymmetrical / Asymmetrical



All product specifications are subject to change without notice. Industralight assumes no responsibility of errors or omissions. Please confirm product details prior to ordering.
