PL900 POLE MOUNTED LED LUMINAIRE
PL900 is a compact pole mounted luminaire. The product features an adjustable design with standard spigot entry configurations so is ideal for retrofit projects as well as new installations. PL900 is available in several power options for streetlighting, park and landscapes, security pole lighting, commercial and industrial projects.
ELECTRICAL PARAMETERS
| Input Voltage: | 100-277VAC |
| Power Consumption: | 25W / 50W / 75W / 100W |
| LED Driver Classification: | Constant Current |
| Light Source Classification: | Philips SMD3030 |
MECHANICAL SPECIFICATIONS
| Minimum IK Rating: | IK08 |
| IP Protection Rating: | IP66 |
| Nominal Dimensions: | 215mm |
| Nominal Body Length: | 479mm / 591mm |
| Construction Material: | Aluminium |
| Spigot Configuration: | Suitable for Spigot OD 40-60mm |
| Recommended Ambient Temp: | -20˚C – 60˚C |
CONFIGURATION OPTIONS
● Available in dark grey (silver) or white finish
● Optional sensor and PE photocell by request
● 1-10V dimmable control available by request
PHOTOMETRIC INFORMATION
| Typical Lumen Efficacy: | 130lm/W |
| CCT Colour Temperature: | 3000K / 4000K / 5000K / 5700K |
| Colour Rendering (Ra): | >75Ra |
| Beam Angle/Viewing Angle: | 70˚x140˚ |
CONTROL OPTIONS
PL900 can be customised or configured according to the needs of your project. Dimming and control options are available by special request. Control protocols include DALI, Casambi, Wireless, 1-10V, analogue dimming.
COMPLIANCE & CERTIFICATION
● IESNA2002
● AS/NZS60598, LM79, LM80
● Lifespan: Exceeds 50,000hrs @ L70
ORDERING INFORMATION
| Model Number: | PL900 |
| Specify LED CCT: | 3000K / 4000K / 5000K / 5700K |
| Specify Wattage Size: | 25W / 50W / 75W / 100W |
| Colour Finish: | Dark Grey (GY) / White (WH) / Custom |
| Optional Accessory: | Wall Mounted Spigot Bracket |
| Control Option: | Non-Dimmable / 1-10V / PE Cell / Sensor |
All product details are subject to change without notice. Final specifications may vary.
