Industralight NV200 Wire Suspended LED Fixture

Industralight NV200 is a high-quality fixture for high-end commercial interiors. The fitting incorporates integrated LED light source and opaque diffuser that delivers smooth and effective illumination. NV200 is available in several sizes and configurations. Typical applications include hotels, shopping mall precincts, retail showrooms, corporate fit-outs, hospitality projects, other commercial interior projects.

Electrical Parameters

Input Voltage100-240VAC
Max Power Consumption58W / 102W
LED Driver ClassificationPowerdrive Constant Current
Light Source ClassificationSMD-SSC2824

Mechanical Specifications

IP Protection RatingIP20
Nominal Diameter600mm / 900mm
Fitting Depth90mm
Construction MaterialAluminium with Polycarbonate
Standard Colour/FinishWhite Trim / Black Trim
Recommended Operating Temp-10°C – 45°C

Configuration Options

  • Non standard trim colours available by special request
  • Custom siameter sizes available by special request
  • DALI dimmable LED driver available by request

Photometric Information

Typical Light Source Efficacy110lm/W
CCT Colour Temperatures3000K / 4000K / 6500K
Colour Rendering Index [CRI]>80
Beam Angle / Viewing Angle110°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Series Model NumberNV200
Specify Colour Temp3000K / 4000K / 6500K
Specify Diameter600mm / 900mm
Wattage58W / 102W
Specify Trim ColourWhite / Black
Warranty AvailableExtended Warranty Available
