Industralight NV200 Wire Suspended LED Fixture
Industralight NV200 is a high-quality fixture for high-end commercial interiors. The fitting incorporates integrated LED light source and opaque diffuser that delivers smooth and effective illumination. NV200 is available in several sizes and configurations. Typical applications include hotels, shopping mall precincts, retail showrooms, corporate fit-outs, hospitality projects, other commercial interior projects.
Electrical Parameters
| Input Voltage | 100-240VAC |
| Max Power Consumption | 58W / 102W |
| LED Driver Classification | Powerdrive Constant Current |
| Light Source Classification | SMD-SSC2824 |
Mechanical Specifications
| IP Protection Rating | IP20 |
| Nominal Diameter | 600mm / 900mm |
| Fitting Depth | 90mm |
| Construction Material | Aluminium with Polycarbonate |
| Standard Colour/Finish | White Trim / Black Trim |
| Recommended Operating Temp | -10°C – 45°C |
Configuration Options
- Non standard trim colours available by special request
- Custom siameter sizes available by special request
- DALI dimmable LED driver available by request
Photometric Information
| Typical Light Source Efficacy | 110lm/W |
| CCT Colour Temperatures | 3000K / 4000K / 6500K |
| Colour Rendering Index [CRI] | >80 |
| Beam Angle / Viewing Angle | 110° |
Detailed photometric report and IES files available by request
