Industralight VTN Diffused Polycarbonate LED Batten Fixture

Industralight VTN is a diffused integrated LED batten fixture that is constructed from fire-resistant polycarbonate body and diffuser. VTN fixtures are an ideal replacement for existing fluorescent diffused light fittings and they are best suited for modern commercial environments including offices, storerooms, workshops, garages, schools, work spaces, retail showrooms etc.

Electrical Parameters

Input Voltage:100-240VAC
Power Consumption:10W/12W/15W/20W/24W
LED Driver Classification:Integral, Constant Current
Light Source Classification:Industralight SMD2835 LED


Mechanical Specifications

Minimum IK Rating:IK08
IP Protection Rating:IP20
Nominal Fixture Lengths:640mm/758mm/908mm/1192mm/1575mm
Construction Material:Fire Resistant Toughened Polycarbonate


Configuration Options

  • Surface mounted LED batten
  • 2HR emergency lighting versions available (1192mm & 1575mm types only)
  • 24VDC version available by special request


Photometric Information

Typical Lumen Efficacy:110lm/W
CCT Colour Temperatures:3000K/4000K/5000K/6500K
Colour Rendering Index (CRI):>90
Beam Angle/Viewing Angle:120°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.  Please see our warranty policy for full details

Series Model Number:VTN Diffused LED Batten
Specify Wattage:10W/12W/15W/20W/24W
Specify Fixture Length:640mm/758mm/908mm/1192mm/1575mm
Specify Colour Temp:3000K/4000K/5000K/6500K
Emergency Lighting Version:2HR Emergency Optional (1192mm & 1575mm)

All product specifications are subject to change without notice. Industralight assumes no responsibility of errors or omissions. Please confirm product details prior to ordering.
