KLS440 Surface Mount LED Wall Light
Industralight KLS440 is an exterior wall mounted fitting with integral LED driver and SMD LED light source. The fitting is entirely surface mounted making it ideal for installation onto solid walls such as concrete or masonry. KLS440 is ideal for pathways and steplighting and can be fitted with an integral PIR sensor for a simple automation solution.
Electrical Parameters
| Input Voltage | 220-240VAC |
| Max Power Consumption | 9W |
| Light Source Classification | Epistar SMD LED |
Mechanical Specifications
| Mounting | Surface Mounted |
| IP Protection Rating | IP54 |
| Nominal Dimensions | 200x90x34mm |
| Construction Material | Aluminium |
| Standard Colour/Finish | Dark Grey |
| Recommended Operating Temp | -10°C – 40°C |
Configuration Options
- Non standard colours available by special request
- Optional 24VDC constant voltage version by request
Photometric Information
| Typical Light Source Efficacy | 85lm/W |
| CCT Colour Temperatures | 3000K / 4000K / 6500K |
| Colour Rendering Index [CRI] | >80 |
| Beam Angle/Viewing Angle | 120° |
Detailed photometric report and IES files available by request
