KLS440 Surface Mount LED Wall Light

Industralight KLS440 is an exterior wall mounted fitting with integral LED driver and SMD LED light source. The fitting is entirely surface mounted making it ideal for installation onto solid walls such as concrete or masonry. KLS440 is ideal for pathways and steplighting and can be fitted with an integral PIR sensor for a simple automation solution.

Electrical Parameters

Input Voltage 220-240VAC
Max Power Consumption 9W
Light Source Classification Epistar SMD LED

Mechanical Specifications

Mounting Surface Mounted
IP Protection Rating IP54
Nominal Dimensions 200x90x34mm
Construction Material Aluminium
Standard Colour/Finish Dark Grey
Recommended Operating Temp -10°C – 40°C

Configuration Options

  • Non standard colours available by special request
  • Optional 24VDC constant voltage version by request

Photometric Information

Typical Light Source Efficacy 85lm/W
CCT Colour Temperatures 3000K / 4000K / 6500K
Colour Rendering Index [CRI] >80
Beam Angle/Viewing Angle 120°

Detailed photometric report and IES files available by request
