Industralight VBN/VBN-LK Polycarbonate Linear LED Fixture

Industralight VBN is a multi-purpose linear LED fixture that is constructed from fire-resistant polycarbonate. VBN fixtures are available in either regular wiring type or end-entry linkable versions.  Several different length configurations are available and they are ideal for installation into modern commercial environments including offices, storerooms, workshops, schools, retail showrooms etc.

Electrical Parameters

Input Voltage:100-240VAC
Power Consumption:20W/24W/30W/40W/48W
LED Driver Classification:Integral, Constant Current
Light Source Classification:Industralight SMD2835 LED

Mechanical Specifications

Minimum IK Rating:IK08
IP Protection Rating:IP20
Nominal Fixture Lengths:604mm/780mm/990mm/1214mm/1520mm
Construction Material:Fire Resistant Toughened Polycarbonate

Configuration Options

  • Available with back entry wiring or linkable end-entry wiring
  • 24VDC version available by special request

Photometric Information

Typical Lumen Efficacy:110lm/W
CCT Colour Temperatures:3000K/4000K/5000K/6500K
Colour Rendering Index (CRI):>90
Beam Angle/Viewing Angle:120°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.  Please see our warranty policy for full details

Series Model Number:VBR Dual Diffused Profile Series
Specify Wattage:20W/24W/30W/40W/48W
Specify Fixture Length(mm):640mm/761mm/911mm/1195mm/1501mm
Specify Colour Temp:3000K/4000K/5000K/6500K

All product specifications are subject to change without notice. Industralight assumes no responsibility of errors or omissions. Please confirm product details prior to ordering.
