VLE200 WEDGE WALL MOUNTED LUMINAIRE
VLE200 is a durable adjustable wall-mounted luminaire.. Perfect for demanding commercial and industrial projects, it offers versatile up or down lighting configurations. Ideal for building perimeters, security lighting, retail complexes, courtyards etc. A reliable choice for diverse industrial and commercial applications. VLE200 is rotatable and adjustable making it versatile for a range of lighting projects.
ELECTRICAL PARAMETERS
| Input Voltage: | 110-240VAC |
| Power Consumption: | 14W / 24W |
| LED Driver Classification: | Integral Constant Current |
| Light Source Classification: | Citizen COB |
MECHANICAL SPECIFICATIONS
| Minimum IK Rating: | IK10 |
| IP Protection Rating: | IP65 |
| Nominal Dimensions: | 172x52x141mm |
| Construction Material: | Powdercoated Aluminium |
| Available Colour/Finish: | Black / SIlver / White / Custom |
| Recommended Ambient Temp: | -10 ~ +50°C |
| Net Weight: | 1.9KG |
CONFIGURATION OPTIONS
● 12VDC or 24VDC Configuration by Special Request
● Non standard fitting colours available by special request
● Remote mounted DALI Driver by request
● RGB / RGBW / CCT Tunable Configurations by Special Request
PHOTOMETRIC INFORMATION
| Typical Lumen Efficacy: | 100lm/W |
| CCT Colour Temperature: | 2700K / 3000K / 4000K / 6000K |
| Colour Rendering (Ra): | >80Ra |
| Beam Angle/Viewing Angle: | 100° |
CONTROL OPTIONS
This product can be customised or configured according to the needs of your project. Dimming and control options are available by special request. Control protocols include DALI, Casambi, Wireless, 1-10V, analogue dimming.
COMPLIANCE & CERTIFICATION
● IESNA2002
● AS/NZS60598, LM79, LM80
● Lifespan: Exceeds 50,000hrs @ L70
ORDERING INFORMATION
| Model Number: | VLE200 |
| Specify LED CCT: | 2700K / 3000K / 4000K / 6000K |
| Specify Voltage Option: | 110-240VAC / 24VDC |
| Specify Finish/Colour: | Black / Silver / White / Custom |
| Specify Wattage: | 14W / 24W / Custom |
| Control Option: | Non-Dim / Remote DALI / Phase Dim |
VLE200 DIMENSIONS
A: 172
B: 52
C: 141
Unit: mm
VLE200 ADJUSTABLE/TILT FUNCTION :
