Industralight RDL686 IP67 Recessed LED Downlight

Industralight RDL686 LED downlights are general-purpose weatherproof LED fittings that are protected to IP67. They are ideal for outdoor applications, public spaces and commercial projects that require a robust high-grade LED downlight.

Electrical Parameters

Input Voltage:100-240VAC
Power Consumption:8.4W  or  14W
LED Driver Classification:Integral Constant Current
Light Source Classification:Cree XP-G Q3 LED


Mechanical Specifications

Minimum IK Rating:IK07
IP Protection Rating:IP67
Nominal Diameter:130mm Trim
Glass Lens Type:8mm Tempered Glass Lens
Material/Construction:Alloy & Stainless Steel Fixings
Recommended Ambient Temp:-20°C – 45°C


Configuration Options

  • Can be finished in black or silver
  • Non-standard colour finishes available by special request
  • Dimmable LED driver can be factory fitted by special request


Photometric Information

Typical Lumen Efficacy:110lm/W
CCT Colour Temperatures:3200K/4200K/5000K/6500K
Colour Rendering Index (CRI):>75
Viewing Angle:24°  or  36°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.  Please see our warranty policy for full details.

Series Model Number:RDL686
Specify Wattage:8.4W   or  14W
Specify Colour Temp:3200K/4200K/5000K/6500K
Specify Beam Angle:24°   or   36°
Specify Trim Colour:Black or Silver
Optional Dimmable:Factory-Fitted by Request

All product specifications are subject to change without notice. Industralight assumes no responsibility of errors or omissions. Please confirm product details prior to ordering.
