KWL502 IP65 LED WALL LUMINAIRE
KWL502 is a high-quality LED luminaire, constructed from extruded aluminium with corrosion resistant powdercoated surface. KWL502 is suited to commercial and domestic projects where a high quality product is required.
Electrical Parameters
| Input Voltage: | 220-240VAC |
| Power Consumption: | 12W |
| LED Driver Classification: | LED Logic, Constant Current |
| Light Source Classification: | CREE CXA2502 (12W) C0B |
Mechanical Specifications
| Minimum IK Rating: | IK09 |
| IP Protection Rating: | IP65 |
| Overall Height: | 205mm |
| Body Diameter: | 90mm |
| Overall Projection From Wall: | 118mm |
| Construction Material: | Aluminium with Glass Visor |
| Standard Colour/Finish: | Black / White / Silver / Custom |
| Recommended Ambient Temp: | -15°C – 55°C |
Configuration Options
- Non standard colours available by special request
- Remote mounted DALI dimmable LED driver available
Photometric Information
| Typical Lumen Efficacy: | 115lm/W |
| CCT Colour Temperature: | 3000K / 4000K / 6000K |
| Colour Rendering Index (CRI): | >85Ra |
| Beam Angle/Viewing Angle: | 10° / 30° / 60° |
Control Options
This product can be customised or configured according to the needs of your project. Dimming and control options are available by special request. Control protocols include DALI, Casambi, Wireless, 1-10V, analogue dimming.
