ATR4100 Industrial LED Canopy Fixture

Industralight ATR4100 is an industrial grade commercial fixture for ceiling and canopy lighting. The uniquely designed housing ensures optimum thermal management for the integrated LED module. ATR series is easy to install onto a variety of ceiling surfaces and can be used for any industrial or commercial project. Typical applications include carparks, petrol stations, warehouses etc.

Electrical Parameters

Input Voltage 100-260VAC
Power Consumption 100W
LED Driver Classification Integral, Constant Current
Light Source Classification Epistar SMD

Mechanical Specifications

Minimum IK Rating IK10
IP Protection Rating IP65
Nominal Dimensions 460x460mm
Overall Depth 105mm
Construction Material Die Cast Aluminum
Standard Colour/Finish Corrosion Resistant Surface Treatment
Recommended Operating Temp   20˚C – 50˚C

Configuration Options

  • Non standard colours available by special request
  • DALI dimmable LED driver available by request

Photometric Information

Typical Lumen Efficacy 100lm/W
CCT Colour Temperatures 3000K / 4000K / 6500K
Colour Rendering Index (CRI) >80
Beam Angle/Viewing Angle 110°

Detailed photometric report and IES files available by request

Download data sheet Talk to a specialist
