Industralight IL9621 OPTO-21 LED Floodlight

Industralight Opto-21 is a high-quality LED floodlight projector suitable for indoor & outdoor illumination projects. The fitting has a compact design with efficient thermal heatsink design, making it suitable for all small to medium applications. Opto-21 is supplied with adjustable bracket and is available in single colour or RGB configuration.

Electrical Parameters

Input Voltage24VDC
Max Power Consumption20W
LED Driver ClassificationConstant Voltage
Light Source ClassificationCREE XPE
LED Colour ConfigurationSingle Colour / RGB
RGB Control ProtocolDMX512 / PWM / RGB Control

Mechanical Specifications

Minimum IK RatingIK09
IP Protection RatingIP65
Body Diameter120mm
Overall Height170mm
Construction MaterialAnodised Aluminium
Standard FinishCorrosion Resistant Anodised
Recommended Operating Temp-15°C – 50°C

Configuration Options

  • RGB configuration available by request
  • Remote DALI dimmable LED driver available by request

Photometric Information

Typical Light Source Efficacy80-90lm/W
CCT Colour Temperatures3000K / 4000K / 6500K / RGB
Colour Rendering Index [CRI]>80
Beam Angle/Viewing Angle22° / 45°
RGB Control Range0-100% 256-bit

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Series Model NumberIL9621
Specify Colour Temp3000K / 4200K / 6500K
Optional RGB ConfigurationRGB / DMX512 / PWM Controller
Specify Beam Angle22° / 45°
Warranty InformationExtended Warranty Available
